Semi Automatic Ampoule Washer is a simple, compact, versatile and a reliable ampoule – vial washing machine complies as per GMP requirements. The machine is enclosed in Stainless Steel construction with flexibility to wash 1ml to 20ml ampoules and 2ml to 100ml glass vials with the help of suitable change parts. Machine is specially designed having timer operated solenoid valve system to enhance and derive the best out of simple unit.
The dump loading procedure may be used, if vials are received in ready to dump boxes, which will have exactly into the same number of vials and the pitch, as loading tray. Alternatively, each vial has to be arranged into the tray. The loading tray/s is placed directly into the machine & the handle bar is lowered for automatic centering of washing needles into the vials mouth. The top cover is also lowered & switch is operated for automatic sequential washing both from inside and outside of each individual vial. Machine automatically stops after one complete cycle & for removal of tray, reverse procedure is to be observed. Depending on loading & operator’s efficiency one can achieve 30 loading trays in an hour.
| Model | AAVW 340 | |||
|---|---|---|---|---|
| Ampoule Range | 1ml to 20ml | |||
| Vial Range | 2ml to 100ml | |||
| Production Rate | 1200 to 10000 per hour | |||
| Power Supply | 0.25 H.P. | |||
| Filling Precison | ± 1% | |||
| Electrical Characteristics | 220 Volts, 60 Hertz, 4 Wire System | |||
| Net Weight | 120 Kgs. Approx. | |||
| Gross Weight | B300 Kgs. Approx. | |||
| Net Dimension | 990 mm (L) X 860 mm (W) X 940 mm (H) approx. | |||
| Case Dimensions | 1100 mm (L) X 1050 mm (W) X 1200 mm (H) approx. | |||
| * Power voltage can be adjusted as per customer’s domestic power voltage requirements. * Rights of technical improvements & modification reserved. * Illustrations & dimensions are shown for information purpose only. |
||||
